| Project | : | Qatar Rail Metro Underground Gold Line |
| Client | : | Q-RAIL QATAR |
| Consultant | : | WorleyParsons QATAR |
| Contractor | : | ALYSJ JV QATAR |
| Code Used | : | ASCE. |
| Scope | : | CCPPlantSupportAnalysis &Design |
Description
- Performed support selection &analysis for supports of Critical piping sizes of 700 DIA & above.
- Performed structural Design for shoe plate for all types of support(Rest, Rest+Guide,Hold-down+Guide,3-way restraint).
- Prepared shop drawing for all types of support(Rest,Rest+Guide,Hold- down+Guide,3-way restraint).
